Sister’s wedding

[2022-07-18] #Rust #GeneticAlgorithm #WASM

Article is being checked ;) the demo works only on firefox for now.

Live snippet

Full result at the end of the article ;)

My sister is getting married!

We’re talking about serious things!!

Speaking with my sister, we talked about some people at the wedding who can’t be together at the table. Then, we felt about the issue, how to propperly position people? For example, I want to be with my girlfriend and my daughter, but Barney wants to be with his crush, who doesn’t want to speak with her ex-best friend! Multiply that kind of story by 100, and you finish with a wedding burnout.

One of the firsts little easy algorithm I learned is the genetic one. And May be it can help my sister to do his table plan… I’ll do a special article with a code snippet.

Code

A genetic algorithm is just a smart method to bruteforce a problem such as the famous “Traveling salesman”. You’ll never be sure that the result is the best. Nevertheless, you’ll have a better result than an approximation, and in a reasonable time.

I’m not going to explain step by step the principle of the genetic method. If you’re interested, you can look at these videos of The coding train channel.

I propose to show, how with perhaps 200 lines of rust I can write a web library with a genetic algorithm, specific for a table’s plan.

Types

When I start a genetic algorithm, I like to start with the definition of DNA. An option for our case is to use a vector of tables and store the names of the participants.

type Dna = Vec<Vec<String>>;

A way to judge a DNA, is to create penalties and bonuses. Penalties are applied when two participants who are not “compatible” are in the same table. I give bonuses similarly, when good friends are together.

Penalty key: two names separated with a coma in alphabetical order. Penalty value: value of the penalty. (0 to 255)

pub type Penalties = HashMap<String, u8>;
pub type Bonus = HashMap<String, u8>;

Number of people in the population. I Don’t need much, 100 is more than enough. If we want a better result, we prefer to increase the number of generations.

static N: usize = 100;

Evaluation

There is no genetic algorithm without evaluations! The function will compute a value from a DNA, then we will order the bests rated candidates and merge them together.

The evaluation can be very naive! If two people with a bonus are at the same table, we add the bonus’s value. If two people with a penalty are at the same table, we subtract the penalty’s value (all of that in the range of an unsigned 32 bits integer)

pub fn evaluation(dna: &Dna, penalties: &Penalties, bonus: &Bonus) -> u32 {
    let mut ret = 0i64;
    for table in dna {
        let couples =
            HashSet::<String>::from_iter(table.iter().combinations(2).map(|c| couple(c[0], c[1])));
        for couple in couples.iter() {
            ret += 1;
            if let Some(v) = bonus.get(couple) {
                ret = ret.saturating_add(*v as i64);
            } else if let Some(v) = penalties.get(couple) {
                ret = ret.saturating_sub(*v as i64)
            }
        }
    }
    match ret.try_into() {
        Ok(ret) => ret,
        _ => 0,
    }
}

Merging (reproduction)

Once you have a population (the list of DNAs), and you have evaluated each person. You can order them and “merge” the half of the bests between them.

To merge two DNAs, you call that function. It will shuffle some places and create a new random one.

What do I try to do? First, if a and b are equals, I just return a and avoid useless execution of codes. Then I take the table length, in theory, there shouldn’t be a problem here to take the first element of a.

Then I flatten the names. I have to list of names ordered by there position in the wedding. At the position 0, we have the name of the person at table 1 place 1. At position 1, we have the name for table 1, position 2, etc.

I can shuffle manually the places, taking randomly the piece of DNA from the parent a, or from the parent b. As it would work in the real life I guess.

Note that I also add a possibility to create a random DNA from nowhere. That’s a natural mutation that will add a natural branch of evolution if it’s very good, or just die at the next generation. Sad, but life can be terrible.

To keep coherency, if you choose the one from the parent a, I need to say that b should replace the chosen name by the other.

In other words, for each element in the DNA, I choose to use the second element or restore the first element.

Note: there is probably a lot of cloning that I can avoid! If you want to share an idea you can post a comment ;)

pub fn merge(a: &Dna, b: &Dna) -> Dna {
    if a == b {
        return a.clone();
    }
    let table_length = a[0].len();
    let mut a: Vec<String> = a.iter().flatten().cloned().collect();
    if rand::random::<u8>() > 254 {
        return random(a, table_length);
    }
    let b: Vec<String> = b.iter().flatten().cloned().collect();

    let mut rng = rand::thread_rng();
    let mut pos =
        HashMap::<String, usize>::from_iter(a.iter().enumerate().map(|(i, v)| (v.clone(), i)));
    let mem = a.clone();

    for i in 0..a.len() {
        let n = match rng.gen() {
            true => b[i].clone(), // replace
            _ => mem[i].clone(),  // restore
        };
        let pn = *pos.get(&n).unwrap();
        let o = a[i].clone();
        a[i] = n.clone();
        a[pn] = o.clone();
        pos.insert(n, i);
        pos.insert(o, pn);
    }
    a.chunks(table_length).map(|t| t.to_vec()).collect()
}

That method is similar to merge two hashmaps and taking randomly the value. It’s very long to get goods mutations that way. Sadly, a full shuffle of the DNAs is a better solution right now. The main difference between “bruteforce” and “genetic” is the effort we make to choose and merge the best results, a form of eugenics. Sometimes the data structures help us, not today.

Start and run the simulation!

Obviously, when we will get a list of participant, I want to create a population for my experience. So I’ll call that random method that will create a new DNA from a list of names and a table length.

Ill call that function N times, I don’t need so much, 100 would be great

pub fn random(mut people: Vec<String>, table_length: usize) -> Dna {
    people.shuffle(&mut rand::thread_rng());
    people.chunks(table_length).map(|t| t.to_vec()).collect()
}

Now, we got everything, I can start the genetic algorithm. I take in input a population, some penalties, some bonus, the number of participants in a table. And a log function for reporting progress in a callback.

The times input significate the number of generations of the genetic evolution.

I also want to return the latest bests DNA in my population. As well, I can call run or rerun, where run will create a random population, and rerun will use a population in input (and that is convenient that the input is the previous bests returned by run).

fn intern_run(
    times: usize,
    mut population: Vec<Dna>,
    penalties: Penalties,
    bonus: Bonus,
    log: fn(Vec<Vec<String>>, usize),
) -> Vec<Dna> {
    let mut rng = rand::thread_rng();
    let mut ret: Vec<Dna> = vec![];
    for i in 0..times {
        let bests: Vec<&Dna> = population
            .iter()
            .sorted_by_cached_key(|dna| Reverse(evaluation(dna, &penalties, &bonus)))
            .take(N / 2)
            .collect();
        log(
            bests[0].clone(),
            evaluation(bests[0], &penalties, &bonus) as usize,
        );
        if i == times - 1 {
            ret = bests.iter().cloned().cloned().collect();
        }
        population = (0..N)
            .map(|_| {
                merge(
                    bests[rng.gen_range(0..N / 2)],
                    bests[rng.gen_range(0..N / 2)],
                )
            })
            .collect();
    }
    ret
}

Then some bindings with wasm-bindgen and I do the glue! Easy like that! You can use the package, since there is no multithreading, and no thread locks, it compile like a charm. The JSON serialization could be modified I think, creating more glue manually, but not now!!

#[wasm_bindgen]
pub fn run(
    times: usize,
    people: String,
    penalties: String,
    bonus: String,
    table_length: usize,
) -> String {
    let _: HashMap<String, u8> = match serde_json::from_str(&penalties) {
        Ok(p) => p,
        Err(e) => {
            elog(&e.to_string());
            panic!()
        }
    };
    serde_json::to_string(&algo::run(
        times,
        serde_json::from_str(&people).unwrap(),
        serde_json::from_str(&penalties).unwrap(),
        serde_json::from_str(&bonus).unwrap(),
        table_length,
        |dna, e| {
            #[allow(unused_unsafe)]
            unsafe {
                log_best(serde_json::to_string(&dna).unwrap(), e)
            }
        },
    ))
    .unwrap()
}

Thank you for reading! I’ll share soon the full code of the project. Bellow you can look at the full result of the computed table plan. The time you read that, a lot of generations have lived and now, you have one of the best possible proposal!

You can create you’re own list of participants by resetting the example, and adding the names (press enter to add a name), and adding bonus / penalty (name1 [space] name2, [number value]). Note that it probably work better if you prefer to use more bonus than penalties.

Good day!
